Bitonal Command
Smartsite 7.8 - ...
The Bitonal command applies a bi-tonal effect to the image, using the two specified colors.
The specified darkcolor replaces the darker colors of the image, and the lightcolor replaces the lighter colors of the image.
The threshold determines which pixels/colors are replaced by which of the two.
Available as of Smartsite 7.8.
Parameters
| Shorthand | Values |
|---|---|
| bitonal | Set to 1 to apply the bi-tonal effect. |
| lightcolor | The color name or HEX value, e.g. khaki or F0E68C (required). |
| darkcolor | The color name or HEX value, e.g. blue or 0000FF (required). |
| threshold | The threshold value (defaults to 100). |
Command definition
| XML |
Copy Code
|
|---|---|
<add id="bitonal" type="Smartsite.ImageProcessor.Commands.BitonalCommand, Smartsite.ImageProcessor" enabled="true"> <parameters> <add name="bitonal" shortcut="bitonal" /> <add name="darkcolor" shortcut="darkcolor" /> <add name="lightcolor" shortcut="lightcolor" /> <add name="threshold" shortcut="threshold" /> </parameters> </add> |
|
Examples
Original image
Bi-tonal effect using black and orange-red (?hid=img;bitonal=1;darkcolor=black;lightcolor=orangered;threshold=350;)
Bi-tonal effect using blue and khaki (?hid=img;bitonal=1;darkcolor=blue;lightcolor=khaki;threshold=350;)
